Perkins M216C - Page 118

118 KENR9126
Troubleshooting Section
g01173226
Illustration 19
Typical example of the oil pres sure sensor
(1) Voltage Supply (Vs)
(2) Ground (GND)
(3) Signal (SIG)
g01173226
Illustration 20
Typical ex ample of the transmission oil pressure sensor
(1) Voltage Supply (Vs)
(2) Ground (GND)
(3) Signal (SIG)
g01173224
Illustration 21
Typical example of the fuel pressure sensor
(1) Voltage supply (Vs)
(2) Ground (GND)
(3) Signal (SIG)
g01173225
Illustration 22
Typical exam ple of the ex haust gas temperature s ensor
(1) Voltage Supply (Vs)
(2) Ground (GND)
(3) Signa l (SIG )
