IOLAN
+
- User and Administration Guide
Flow Control
The Flow Control section shows and allows changes to the
flow control fields as described in
The Port Menu - Flow
Control Section
above.
** Administrator ** FLOW CONTROL MENU REMOTE-ADMIN
TTY Flow ctrl Input Flow Output Flow
1 [XON/XOFF] [Enabled ] [Enabled ]
2 [Hardware] [Enabled ] [Enabled ]
Figure 43: Lines - Flow Control Menu.
Hardware
The Hardware section shows and allows changes to the
hardware control fields as described in
The Port Menu -
Hardware Section
above.
** Administrator ** HARDWARE MENU REMOTE-ADMIN
TTY Speed Parity Bit Stop Break Monitor DSR Monitor DCD
1 [57600 ] [None] [8] [1 ] [Disabled] [No ] [No ]
2 [115200] [None] [8] [1 ] [Disabled] [No ] [Yes]
Figure 44: Lines - Hardware Menu.
Network
Connections
The Network Connections section shows and allows changes
to some of the Access fields as described in
The Port Menu -
Access Section
above.
** Administrator ** NETWORK CONNECTIONS MENU REMOTE-ADMIN
TTY Name Connection Remote Host Remote Port Local Port
1 [mark ] [Dedicated] [204.17.209.6 ] [23 ] [2 ]
2 [alan ] [Dedicated] [204.17.209.6 ] [23 ] [3 ]
Figure 45: Lines - Network Connection Menu.
