18
IOLAN
+
- User and Administration Guide
Connection Host
1 *** FREE ** === Commands ===
2 *** FREE ** | Telnet ^T|
3 *** FREE ** | Rlogin ^R|
4 *** FREE ** | Port ^P|
| Admin mode ^A|
| CLI |
| Lock |
| Logout ^D|
================
________________________________________________________________________________
This option allows you to configure parameters affecting
the Server box, eg hosts table, other terminals.
IOLAN+RACK v4.02 a CDi IOLAN+
Figure 9: Commands pop-up menu.
Before communication across the network can be established
the IOLAN+ must be assigned a network IP address. This is
accessed through the
Administration Menu .
Select the
Admin mode field and press the
key.
Note: If you are telneted into IOLAN+, the
telnet , rlogin and
port options do not appear on the Commands pop-up menu.
Administration
Menu
The top level Administration Menu appears as follows:
ADMINISTRATION MENU REMOTE-ADMIN
gateway Examine/modify gateway table.
host Examine/modify host table.
line Terminal configuration organised by line.
password Specify password to allow modification of menu items.
port Terminal configuration organised by port.
quit Return to connections menu.
server Examine/modify Server parameters.
stats Examine Server statistics.
________________________________________________________________________________
Figure 10: Administration Menu (view level).
