Cabling Guide
C.2 Standard
Modem
Cables
1
2
3
4
5
6
7
8
20
IOLAN+
DTE
(DB25)
Modem
DCE
(DB25)
1
2
3
4
5
6
7
8
20
Gnd
TXD
RXD
RTS
CTS
DSR
Gnd
DCD
DTR
Gnd
TXD
RXD
RTS
CTS
DSR
Gnd
DCD
DTR
Figure 64: IOLAN+ Standard Modem Cable
2
3
4
5
6
7
8
20
IOLAN+
IOLAN+
102/104
DTE
(RJ45)
Modem
DCE
(DB25)
1
2
3
4
5
6
7
8
DCD
RTS
DSR
TXD
RXD
Gnd
CTS
DTR
TXD
RXD
RTS
CTS
DSR
Gnd
DCD
DTR
Figure 65: IOLAN+ , IOLAN+ 102/104
Standard Modem Cable
