Setting up Dial-in Modem Ports
Setting up Dial-in Modem Ports 4
This section will review the configuration necessary to create
dial-in connections. It will start with the most simple
connection such as a dial-in Unix connection. The section
then moves into setting up PPP ports which is how Windows
®
systems dial-in (as well as Unix). This is very important if you
are an Internet Service Provider (ISP) or a corporate site
providing remote access or Internet/Intranet access.
IOLAN+ can make a very good dial-in solution for ISPs and
corporate users alike by using its remote access facilities.
This section goes hand-in-hand with the next section,
Modem Authentication and Logging
.
Note: In many of the modem examples, we are using PPP.
You can use SLIP and CSLIP in those applications requiring
these legacy modes.
4.1 Dial-in Port
Configuration
The following is the port configuration for a dial-in
connection, including PPP.
** Administrator ** PORT SETUP MENU REMOTE-ADMIN
Hardware Flow ctrl Keys
Speed [57600 ] Flow ctrl [Hardware] Hot [^@] Intr [^@]
Parity [None] Input Flow [Enabled ] Quit [^@] Kill [^@]
Bit [8] Output Flow [Enabled ] Del [^@] Sess [^@]
Stop [1 ] Echo [^@]
Break [Disabled] IP Addresses
Monitor DSR [No ] Src [ ] Mask [255.255.255.0 ]
Monitor DCD [Yes] Dst [204.17.209.101 ]
User Options Access
Name [ ] Keepalive [No ] Access [Local ]
Terminal type [ansi ] Rlogin/Telnet [Telnet] Authentication [Host ]
TERM [ ] Debug options [No ] Mode [Raw ]
Video pages [0] Map CR to CR LF [No ] Connection [Dedicated]
CLI/Menu [CLI ] Hex data [No ] Host [204.17.209.1 ]
Reset Term [No ] Secure [Yes ] Remote Port [513 ]
MOTD [No ] Local Port [10006]
________________________________________________________________________________
Figure 18: Port Setup Menu for PPP connections.
