20
IOLAN
+
- User and Administration Guide
** Administrator ** SERVER CONFIGURATION REMOTE-ADMIN
Name [IOLAN ] Debug mode [0 ]
IP address [204.17.209.8 ]
Subnet mask [ ]
Ethernet address [00:80:d4:00:9e:a1] Ethernet interface [AUTO ]
Language [English ]
Identification [ ]
Lock [Disabled]
Password limit [5 ]
CR to initiate [Yes ]
SNAP encoding [Disabled]
Boot host [204.17.209.1 ] Boot diagnostics [Enabled ]
Boot file [ ]
Init file [ ]
MOTD file [ ]
Domain name [ ]
Name server [ ] NS Port [53 ]
WINS server [ ]
________________________________________________________________________________
Figure 12: Server Configuration menu.
The important fields that you need to fill in are as follows:
Name: In the example above the communications
server name has been set to
IOLAN
. It is a good
idea for the IOLAN+ name entered here to
match the name entered in the host machine’s
domain name server.
Note: For more information about domain name servers,
consult your operating system manuals.
IP Address: This address must be set to a value that is
consistent with the network the IOLAN+ is on.
Having filled in the fields press the
key. This brings the
Commands
pop-up menu as shown below.
Note:
The Ethernet address is factory set. This address is
uniquely assigned to the IOLAN+ and MUST NOT be changed
.
