PHYSICAL SETUP: RF SETUP
4
Repeat Steps 1 - 3 for
the remaining two RF
antennas.
5
Align the SMA connec-
tor on the GPS antenna
with the SMA connector
on the unit.
6
Twist the antenna clock-
wise until it is fully mated.
