Petsafe IF-100 - Installation Instructions

Lightning
Protector
Instructions
INSTALLATION INSTRUCTIONS
The Lightning Protector takes only minutes to install:
1.Turn off your containment system. If your pet is in the containment area, make
sure that it is otherwise contained, or bring it inside.
2. Do not begin installation if there is visible lightning in the area or if you hear
thunder.
3. Plug the Lightning Protector into a grounded (3-prong) household outlet (120V
AC) within five feet (5') of where you want to position the transmitter. The green
power light should illuminate, indicating the Lightning Protector is powered. If the
green light does not illuminate, recheck all connections.
NOTE: Avoid using an AC outlet protected with a ground fault current interrupter
(GFCI).The containment system and the Lightning Protector will function properly
in a GFCI outlet, but in rare cases lightning strikes may cause the GFCI to trip,
and you will have to reset it in order for your containment system to function prop-
erly.
4. Cut the in-ground loop wires near the Lightning Protector and strip 1/4" insula-
tion from their ends.
5. Insert the stripped ends of the in-ground loop wire into the left two red connec-
tor holes on the bottom of the Lightning Protector. Use your finger to depress the
tab, then insert the wire and release the tab (see diagram).
Insert the ends of the two transmitter wires into the right two black connector
