Adjustment
34
000 015 Reduced current for stepping motors ON – OFF ON
The reduction function of the holding
current at rest with closed button clamp
is switched on or off.
016 Key tone ON – OFF ON
The key tone, as reaction to a key on
the control panel being pressed, is
switched on or off. The double tone
for incorrect inputs always remains
switched on.
017 Button clamp solenoid 5 – 100 10
Operating time [10 ms]
The time, for which the solenoid is
under full current, is entered.
018 Button clamp solenoid duty-cycle [%] 5 – 100 20
At the end of the clamp solenoid
operating time (Parameter "017") the
solenoid is clocked. The relationship
between duration of operation and
non-operation is entered here.
019 Thread trimming solenoid 5 – 100 25
operating time [10 ms]
The time, for which the solenoid is
under full current, is entered.
020 Thread trimming solenoid duty-cycle 5 – 100 100
At present without a function
021 Thread take-up lever t.d.c. [°] 45 – 53 51
The position for the t.d.c. thread
take-up lever is entered here. If the
function is executed, the position can
be set by turning the balance wheel.
The access code is necessary for this
adjustment.
022 Thread trimming position
(in relation to t.d.c. needle) [°] 180 - 253 180
The position, at which the thread
trimming solenoid is switched on, is
entered here. The adjustment is set
by turning the balance wheel.
The access code is necessary for this
adjustment.
Group Parameter Description Setting Set value
range
