Adjustment
35
000 023 Sewing area size X [1/10 mm] ± 33 -23 / +23
To avoid mechanical collisions, the
sewing area size of the button clamp
in use is entered. The control unit
checks the path and, if necessary,
issues an error message.
024 Sewing area size Y [1/10 mm] ± 33 -23 / +23
To avoid mechanical collisions, the
sewing area size of the button clamp
in use is entered. The control unit
checks the path and, if necessary,
issues an error message.
025 Thread wiper solenoid
operating time [10 ms] 5 – 100 10
The time, for which the solenoid is
under full current, is entered.
026 Thread wiper solenoid Duty-cycle [%] 5 – 100 100
Thread wiper solenoid, ratio on-time to
off-time in % (Duty-Cycle)
027
Basic position/loading point = zero point ON - OFF OFF
100 101 Software version main processor 0300.xxx
The software version of the main
processor is displayed
102 Software version sewing drive unit V.xx
The software version of the sewing
drive module is displayed.
103 Software version control panel V.xxx/ H.xxx
The soft- and hardware version of the
control panel are displayed.
200 201 Program number 50 - 99 50
The program number of the program
to be processed is selected.
202 Button hole model 2 – 4 2
The button hole model (number of
holes in the button) is selected.
203 Coordinates of the first hole xx.yy
The coordinates of the hole are entered.
204 Coordinates of the second hole xx.yy
205 Coordinates of the third hole xx.yy
206 Coordinates of the fourth hole xx.yy
Group Parameter Description Setting Set value
range
To Next Page
