Adjustment
36
200 207 Coordinates of the fifth hole xx.yy
208 Coordinates of the sixth hole xx.yy
209 Stitch positions 1 - 20 4
The number of stitch positions on one
edge are entered.
210 Stitch formation 0 – 2 0
The stitch formation depends on the (0 – 3)
type of button selected, see Chapter
11.04 Free input of the seam pattern
(Teach in) of the instruction manual.
Three-hole button:
0 = cycle, 1 = point, 2 = stitching
Four-hole button:
0 = normal, 1 = cycle, 2 = arrow, 3 = Z
211 Intermediate trimming ON - OFF OFF
On four-hole buttons the thread can
be trimmed between the second and
third hole.
211 Number of sewing-on stitches 2 -10 2
212 Number of attaching stitches 2 -10 4
600 601 Display inputs
With this function the digital inputs can
be checked. "IN" shows the input
numbers (1 – 16). Under "VAL" the
respective switch status is displayed.
IN VAL
1 IN1, programmable input 1
2 IN2, programmable input 2
3 E3, button clamp raised
4
5
6
7
8
9
10
11
12
13
14
15
16
Group Parameter Description Setting Set value
range
