Page #40 background imageLoading...
Page #40 background image
Adjustment
37
600 602 Display special inputs
With this function it is possible to
check the special inputs pedal,
reference X (SM1) and reference Y
(SM2). "IN" shows the inputs (PED,
REFX, REFY). Under "VAL" the
respective switch status is displayed.
IN VAL
PED Pedal (speed control unit
-1; 0; +1; 2)
REFX Reference input X
REFY Reference input Y
603 Connect outputs
With this function the outlets can be
connected. "OUT" shows the outlet
selected (1-16). Under "VAL" the
selected output is set (S) with the
plus/minus key (+), and reset (R) with
the plus/minus key. Interlocks are
checked. Non-assigned outlets are not
connected.
OUT VAL
1 S/R Solenoid for
button clamp open
2S/R
3 S/R Solenoid for
thread trimming
4 S/R Solenoid for
thread wiper
5S/R
6 S/R Program outlet
7 S/R Program outlet
8S/R
9S/R
10 S/R
11 S/R
12 S/R
13 S/R
14 S/R
15 S/R
16 S/R
604 Move stepping motors
The stepping motors SM1 (X-axis) and
SM2 (Y-axis) are moved individually
with the respective plus/minus keys.
Interlocks are not checked.
Group Parameter Description Setting Set value
range
