Adjustment
38
600 605 Turn sewing motor 500 - 2500 500
The sewing motor can be operated
with a selectable set speed by
pressing the pedal. After the sewing
motor has been started, the current
speed is also displayed.
606 Thread trimming sequence
The sequence for a complete thread
trimming cycle is started with the
plus/minus key (+) below CUT and
below THR.
607 Cold start (RESET)
With this function the control unit
carries out a cold start (RESET) with
which the data is reset. After this
function has been selected, the
machine must be switched off and
then on again.
608 Setting zero points
With this function and the adjustment
gauge, the zero points for the X/Y-drive
unit can be set. (stepping motor
correction values for the reference
points REFX, REFY). The access code
is required for this adjustment.
609 Setting the button clamp centre X
This function is used to set the centre
of the button clamp in X-direction.
When entering the function, the
machine moves to the current button
clamp centre, after which it is possible
to move to the right or left edge,
depending on the set limits
(param. "023"). A correction can be
made with the plus/minus keys.
The relocation value is displayed.
610 Setting the button clamp centre Y
This function is used to help set the
centre of the button clamp in
Y-direction. After entering this function,
the machine moves to the current
button clamp centre, after pressing a
key to the front or the rear limit
(param. "024"). The button clamp must
be shifted manually.
Group Parameter Description Setting Set value
range
