Operating Controls
17
7.04.01 Symbols on the display
In addition to clear texts and set values, the following symbols appear on the display.
Symbol Function
Current program number
Piece counter
Speed
Stitch length
SD memory card
Machine memory
Enter
7.04.02 Plus/minus keys
The corresponding set values are selected and altered using the appropriate plus-minus
keys. At the same time the set value shown above is changed slowly at fi rst by pressing
and holding the corresponding plus or minus key. If the key is held pressed for longer, the
set value changes more quickly.
Fig. 7 - 05
F1
F2
F3
F4
0
0
0
0
0
0
3500 1 3,5 2000
Plus/minus keys
The displayed values can be increased or decreased using the respective key on the display
+
–
