Pfaff 3538-30/02

Input
32
10.09 Parameter list
Function group 100: Operator level
101 Display software version (0437/xxx)
102 Display motor control software version
103 Key beeper (I = OFF, II = ON)
104 Needle thread monitor (I = OFF, II = ON)
105 Bobbin thread monitor (I = OFF, II = ON)
106 Display serial number of machine
Function group 200: Mechanic level
201 Subclass(x)
1: 3538-1/01 (Basic)
2: 3538-1/02 (with chain cutter)
3: 3538-1/03 (with chain cutter and stacker)
202 Label feeder attached (I = OFF, II = ON)
203 Band feed acceleration (200; 50 – 999)
204 Band feed braking (250; 50 – 999)
205 Maximum stitch length when sewing in 1/10 mm
(4.0; 2.0 – 8.0)
206 Switching frequency from fi ne step to full step
(375; 0 – 2000)
207
(2,3)
Automatic extraction (I = OFF, II = ON)
Function group 300: Positions
301
Reference position (needle at top edge of needle plate)
302
Position of cover-thread carrier t.d.c. (153, 0 – 191)
303
Position of needle at bottom position (81, 0 – 191)
Function group 400: Times (0.01 – 2.00 s)
401 Holdoff time after initial light barrier (0.01 s)
402 Switching time for needle head to move to thread-in
position (A7) (1.00 s)
403 Wait period after sensor when sewing head in sewing
position (A7) (0.10 s)
404 Switching time to raise/lower band feed (A6) (0.85 s)
405 Switching time of presser foot upwards (A10)
(0.20 s)
406 Switching time of presser foot downwards (A10)
(0.20 s)
407 Needle thread monitor hide stitches (3, 0 – 9)
408 Bobbin thread monitor hide stitches (3, 0 – 9)
409
(2,3)
Chain cutter switch-on time (A8) (0.01 s)
