10.02 Sewing – Unit with cutter and rack
In contrast to the basic machine described in 10.01, the “Plus” machine sepa-
rates the pocket blanks after hemming with a cutter. An integrated extraction
device removes the loose threads during the cutting process and collects them
in a container under the work table. The individual pocket blanks are automati-
cally fanned out with an automatic racking device and placed on a round table.
 Turn on the machine at the main switch and wait for it to be ready for operation.
 Press the presser foot key and raise the presser foot.
 Lay the top edge of the pocket blank at the stop.
 Slide the pocket blank to the left under the Plexiglas cover.
 Light barrier detects the start of the pocket blank.
 Feed band moves the pocket blank to the left into the pleating attachment.
 Pleating attachment folds over the top edge.
 Feed band moves the folded pocket blank into the sewing position.
 Top edge seam is sewn.
 Pocket blank is transported out of the sewing area.
 Light barrier triggers the “Cutting” process.
 Pneumatically operated blade separates the continuing seam.
 Feed band transports the pocket blank to the rack.
 Rack moves back and opens the passage downwards.
 Pocket blank falls down onto the round table.
 Pneumatic cylinder switches the round table one step further.
 Rack moves forward and closes the passage.
 Unit is ready for the next pocket blank.
 The blanks can be removed when the round table is full.
