Set-up
24
9 Set-up
Observe and comply with all regulations and instructions in this instruction
manual.
Pay particular attention to all safety regulations!
All set-up work may only be carried out by appropriately instructed personnel.
Disconnect the machine from the electricity mains for all set-up work by operat-
ing the main switch or by removing the mains plug!
9.01 Inserting the needle
Switch off the machine!
Risk of injury due to accidental
machine start-up!
Only use needles of the system
intended for the machine, see
Chapter 3 Technical Data!
Approach the thread-in position (see
P. 18)
Bring the needle bar to the top position
and loosen screw 1.
Insert needle 2 up to the stop (while do-
ing so, the long needle groove must
point to the right).
Tighten the screws 1.
Fig. 9 - 01
1
2
2
1
