Maintenance and Care
39
11.03 Checking / topping up the oil level of the oil tank for the front parts
Fig. 11 - 01
Check the oil level before every start-up.
The oil level must not drop below the “min.” marking or rise above the “max.”
marking.
The oil level must always be visible in the sight glass 1.
Add oil to the container through the hole 2 as needed
Only use oil with a centre viscosity of 22.0 mm
2
/s at 40 °C and a density of
0.865 g/cm
3
at 15 °C.
We recommend PFAFF sewing machine oil part no. 280-1-120 144.
2
min.
max.
1
