Input
33
410
(2,3)
Chain cutter travel time downwards (A8) (0.01 s)
411
(3)
Switching time of stacker downwards (A12) (0.01 s)
412
(3)
Switching time of stacker upwards (A12) (0.01 s)
413
(3)
Switching time of stacker to the right (A13) (0.01 s)
414
(3)
Switching time of stacker to the left (A13) (0.19 s)
415
(3)
Switching time to open stacker (A14) (0.28 s)
416
(3)
Switching time to close stacker (A14) (0.17 s)
417
(3)
Switching time to turn stacker (A4) (0.01 s)
418
(3)
Switching time to hold pocket (A3) (0.01 s)
Function group 500: Counter, speeds and clearances
501 Soft start stitches (0; 0-15) soft start speed (1500; 0 –
4500 rpm)
502 Stop clearance (55.0; 0 – 999.9)
503 Length when fi lling machine (370; 0 – 9999)
504 Speed of band feed in a manual process (like a sewing
head speed with a stitch length of 4 mm)
(2000, 10 – 4000)
505
(2.3)
Clearance of chain cutter sensor to the chain cutter
(16.4; 0 – 999.9)
506
(2.3)
Clearance of start of pocket to the chain cutter
(3.0; 0 – 999.9)
507
(2.3)
Clearance of end of pocket to the chain cutter
(3.0; 0 – 999.9)
508
(3)
Clearance of stacker sensor to the stacker
(90.0; 0 – 999.9)
Function group 600: Service
601 Band feed stepping motor process (X: individual steps,
XX: continuously forwards or backwards while the key
is pressed)
602 Inputs: 0123456789ABCDEF
0: free (E1 – X5.1)
1: free (E2 – X5.2)
2: free (E3 – X5.3)
3: free (E4 – X5.4)
4: free (E5 – X5.5)
5: free (E6 – X5.14)
6: free (E7 – X5.15)
7: Needle thread monitor (option) (E8 – X5.16)
8: Bobbin thread monitor (option) (E9 – X5.9)
