Pfaff 3538-30/02

Input
34
9: Stacker cover (E10 – X5.10) (3)
A: Feed band stop (E11 – X5:11)
B: Stop switch (break contact) (E12 – X5.12)
C: Sewing head in sewing position (E13 – X5.13)
D: Stacker light barrier (E14 – X5.8) (3)
E: Chain cutter light barrier (E15 – X5.6) (2.3)
F: Initial light barrier (E16 – X5.7)
603 Outputs:
1: free (X13.1 and X13.2)
2: free (X13.3 and X13.4)
3: Presser foot (X13.5) ( 1: top, 0: bottom)
4: Raise band feed (X13.6) (1: top)
5: Lower band feed (X13.7) (1: bottom)
6: Sewing head sewing position (X13.8)
7: Sewing head thread-in position (X13.9)
8: Open thread tension (X13.10)
9: Extraction (X13.11) ( 1: on, 0: off) (2.3)
10: Stacker left/right (X13.12) ( 1: left, 0: right) (3)
11: Stacker down (X13.13) ( 1: bottom, 0: top) (3)
12: Open stacker (X13.25) ( 1: open, 0: closed) (3)
13: Hold pocket (X13.24) (3)
14: Turn stacker (X13.16) (3)
15: Chain cutter (X13.17) ( 1: on, 0: off) (2,3)
16: Sewing motor running (X13.18) ( 1: running, 0: at a
standstill)
604 Turn sewing motor in sewing direction
605 Run cold start
606
3
Run stacking process
Function group 700: Sewing motor
701 P-section speed regulator (10)
702 I-section speed regulator (50)
703 P-section position controller (20)
704 D-section position controller (30)
705 Time for position controller (25)
706 P-section position controller for rest brake (25)
707 D-section position controller for rest brake (15)
708 Maximum torque for rest brake (0)
709 Minimum machine speed (6)
710 Maximum machine speed (4500)
