Parts of the embroidery unit
33. Release button for removing the embroidery
unit
34. Under arm guide
35. Fastening latch for attaching to the machine
36. Connection plug to the machine
37. Rotating table for the embroidery arm
38. Metal guide for attaching the embroidery hoop
39. Recessed grip for raising and rotating the
embroidery arm
40. Embroidery arm
41. Release lever for removing the embroidery
hoop
Parts of the embroidery hoop
42. Snap-in pin
43. Two guide pins for attaching the hoop
44. Ribs for fi tting the clips
45. Template placement notches
46. Retaining screw for the fabric
