3:3
33
40
41
38
Embroidery
Remove the embroidery unit
Switch off the main switch.
Press release lever (33) and remove the embroidery unit with a back-
ward movement away from you, holding it parallel to the machine.
Note: Make sure that you have removed the hoop and placed the
embroidery arm in the park position, before removing the embroidery unit.
Attach the hoop on the embroidery unit
The embroidery arm (40) must be rotated, because it is still lying over
the unit. Raise the embroidery arm in the area of the recessed grip (39)
and rotate it 90 degrees. The embroidery arm will lock in embroidery
position.
Pass the hoop underneath the embroidery foot by raising the presser
foot lift as far as possible. The retaining screw of the hoop must be
facing you and the guide pin (43) must be pointing to the right.
Slide the hoop along the machine’s metal guide (38) behind the release
lever (41), until the hoop locks in place.
Remove the hoop
To remove the hoop, push down the release lever (41) of the embroi-
dery unit and pull the hoop forwards and away. The presser foot must
be in the highest position.
