Embroidery preparations
Embroidery unit overview
(type BE16)
A Embroidery unit release button
B Level adjusting feet
C Embroidery unit socket
D Embroidery hoop connection assembly
E Embroidery arm
Note: A larger embroidery unit, with embroidery area
360x350mm, is available to purchase at your local
authorized PFAFF® dealer.
Built-in designs
About 100 designs are included in the memory in
your machine.
Embroidery hoop overview
F Embroidery hoop connector
G Outer hoop
H Inner hoop
I Quick release
J Retaining screw
K Ribs for À tting the clips
L Center marks
