Pfeiffer Vacuum ASM 340 - Control panel description

4.3 Control panel description
5
2
4 3 7
1
6
1 Touchscreen 5 ZERO button
Autozero.
2 Main screen access button 6 Detector connection cable
connector
3 START/STOP button
Test Start/Stop
7 Fixing magnet (x4)
4 CAL button
Internal calibration, external calibration or calibration check is
launched depending on the setting (see chapter “Calibration
type”).
Product description
20/108
