Access: Menu [Advanced] [Input/Output] then [Serial link 1] or [Serial link 2] Choice - Setting limit
Handshake To be selected Yes
No
Module
3)
Read only -
Name
3)
Read only -
Power pin 9
2)
Read only 5 V
1) Default settings: see chapter “Tree diagram of the Settings menu”
2) Serial link 1 only
3) Serial link 2 only
4) 'Spreadsheet' mode only
I/O connector
Access: Menu [Advanced] [Input/Output] [I/O connector]
According to configuration upon order, the detector is equipped with:
●
a 15-pin D-Sub I/O interface
●
a Profibus and 15-pin D-Sub I/O interface
●
a 37-pin D-Sub I/O interface (with USB)
●
an Ethernet and 37-pin D-Sub I/O interface (with USB)
●
a Profinet and 15-pin D-Sub I/O interface
Refer to the interface operating instructions (see chapter « Applicable documents »)
8.6.2 Service
Access to the Service menu is password protected.
Reserved for the Service Centers.
