For quick access from the main screen, configure a function key to [PAGING] (see chapter
“Function keys”).
Leak rate bargraph details
This menu is used to enter the bargraph settings.
Access: Menu [Configuration] [Leak rate bargraph]
Choice - Setting limit
1)
Zoom on set point To be enabled
Zoom on set point is used to display on the bargraph the reject set point
centered on 2 decades.
Enabled
Disabled
High decade To be set
High decade (max) of the bargraph
-12– +6
Low decade To be set
Low decade (min) of the bargraph
-13 – +5
Lower display limit To be set
This limit defines the lower display limit for the measured leak rate.
The measured leak rate is not displayed if it is lower than the set lower dis-
play limit.
1 · 10
-13
– 1 · 10
+06
Show 2
nd
digit
To be enabled
Display of a second digit after the decimal point for digital display of the
leak rate
Enabled
Disabled
1) Initial setting: see chapter “Tree diagram to the Settings menu”
8.3.5 Access - Password
This menu is used to manage the access rights to the various menus and/or screens.
Regardless of the user level, a password is required to access this menu.
The default password is 5555.
The password is not saved in the control panel. If the password is forgotten, it can be found
using the RS-232: see RS-232 operating instructions.
Access: Menu [Configuration] [Access/Password] + password
Choice - Setting limit
1)
User level To be selected
3 user levels can be used to restrict the display and access to settings
and functions.
See details below
Restricted access
Medium access
Full access
Password To be set
This function is used to block access to one or more Settings menus. To
access a locked menu, the user will be asked to provide the password.
-
Customized access To be set
Access to certain items may be permitted or prohibited.
See details below
-
1) Initial setting: see chapter “Tree diagram to the Settings menu”
User level and customized access
The rights defined in the 2 tables below are the default rights for each user level.
These rights can be customized: they can be assigned/withdrawn (see chapter "Access - Password").
Settings menu
73/108
