3
NOTICE
PUMP IS SHIPPED WITHOUT
OIL INSTALLED
Consult operating manual
CAUTION
Wet Model only
This label indicates that the backing pump is drained at the factory.
The oil must be filled before the detector is put into service for the first time.
4 This label indicates that the product must be handled using the devices identified
by this label.
● Comply with the rules for moving the equipment, taking weight and dimen-
sions into account.
5 This label indicates that the product is subject to regulations for the treatment of
electrical and electronic equipment waste (refer to the EC declaration of conform-
ity for the product).
6
1 2
5 6
7
3 4
98 avenue de Brogny F-74000 ANNECY
Kg
P/N :
S/N :
V Hz W
8
Made in France
Product rating plate.
1 Weight 5 Part number
2 Use voltage 6 Description
3 Use frequency 7 Serial number
4 Maximum power consumption 8 Date of manufacture
7 This label indicates that some of the internal parts are electrically live and could
cause electrical shock in case of contact.
● Do not use the product if the main power supply cable is not earthed.
● Disconnect the main power supply cable from the product before servicing
the product.
8 Integrable model only
This label indicates that the connection hole for the external backing pump is on
the rear side.
-
FR AEOF 00165062 - assurance qualité / quality control
This label guarantees to the user that the product packaging has not been
opened since leaving the factory.
-
PRODUIT PERSONNALISE
CUSTOMIZED PRODUCT
This label indicates that the product has been customized at the customer’s re-
quest.
- This label indicates the grounding point on the product.
-
Pu_GL : 1 Pu_N : 1
Mu_GL : 12856 Mu_N : 31
Mu_Cal : 1 Mu_LDS : 1800
For service centers use only
(Example)
-
HLD1302577 - RS232
Bluetooth MAC address
XXXXXX / None
Network MAC address
xx:xx:xx:xx:xx:xx / None
This label indicates the MAC address for the options installed in the product.
(Example)
-
Factory Firmware /Logiciel usine
L0232 V3302 E17D
L0264 V3200 FD87E7D
L0285 V3200 8C9D
DD-MM-YY
1
2 3
4
This label provides information regarding firmware installed in the product.
(Example)
1 Firmware name 3 Firmware checksum
2 Firmware version 4 Publication date
