Access: Settings Screen + Menu [Test] Choice - Setting limit
Dynamic calibration
(Integrable model)
Active Enabled
Disabled
1)
Value
(if 'Active' is enabled)
1 · 10
-19
– 1 · 10
+19
1 · 10
-07 1)
Coefficient
1
1)
-
2)
Purge valve Wet model
Closed
1)
Dry Model
Automatic
1)
Closed
Open
Integrable model Closed
Open
1)
Start-up timer Value 00'00'' – 59'59''
00'10''
1)
Crossover pressures Gross Leak Wet and Dry models
2,5 · 10
+1
– 1 · 10
+1
2,5 · 10
+01 1)
Integrable model
2,5 · 10
+1
– 5 · 10
-1
5 · 10
+00 1)
Normal Wet and Dry models
5 · 10
-1
– 1 · 10
-1
5 · 10
-01 1)
Integrable model
5 · 10
-1
– 5 · 10
-2
5 · 10
-01 1)
1) Default setting
2) General information: read only
Tbl. 4: Default settings: ‘Test’ menu
Access: Settings Screen + Menu [Configuration] Choice - Setting limit
Unit mbar · l/s
Pa · m
3
/s
Torr · l/s
atm · cc/s
ppm
sccm
sccs
mtorr · l/s
-
3)
Date Format: mm/dd/yyyy
-
3)
Time Format: hh:mm:ss
-
3)
1) Default setting
3) No default setting: setting performed by the user at the 1
st
detector start-up
