72
Maintenance
8 Install the foam insulation in the oven. Insert the bottom edge of the foam first so that
the foam is held in place between the oven wall and plate. Next, insert the top half of
the foam into the oven. Ensure that the quartz capillary is not pinched or kinked while
installing the insulation. See Figure 10-10.
Figure 10-10 Re-install foam insulation
9 Install the inlet heater box cover and fasten in place with socket head cap screws.
See Figure 10-11.
Figure 10-11 Re-install inlet heater box cover
