16
Setting Commands (readable and writable)
# Display Name, Description min max fact. set. RS 485
1)
Data typ
2)
002 Standby Stand-by ON/OFF OFF ON OFF
3)
R/W 0
004 RUTime ctr Run-up time monitoring ON/OFF OFF ON ON R/W 0
008 Keys lockd Keyboard interlock –R/W0
009* Error acknowledgement – W 0
010 Pump stat. Pumping station ON/OFF OFF ON OFF
3)
R/W 0
012 Vent enab Venting enable Turbopump ON/OFF OFF ON OFF
3)
R/W 0
019 Conf. OUT2
Config. K2 0= open if mains OFF or failure, 1=dto. or warnings OFF ON OFF R/W 7
2=open if mains OFF, turbo drive OFF or failure
023 Motor TMP Motor Turbopump ON/OFF OFF ON ON
3)
R/W 0
025 OpMode BkP Operation mode backing pump 0=cont. operations; 1=interval oper. 0 1 0 R/W 7
026 OpMode TMP
Operations mode TMP 0=final rotation speed operations; 0 1 0
3)
R/W 7
1=rotation speed setting mode
027 Gas mode Gas mode 0=heavy inert gases; 1=other gases 0 1 0 R/W 7
028 Opmode rem Remote operations mode 0=standard operations, 1=remote priority 0 1 0 R/W 7
029 OpMode drv Selection of the voltage supply; 0=single phase; 1=threephase supp. 0 1 0 R/W 7
030 Vent mode Venting mode 0=automatic venting ; 1=do not vent; 2=venting ”ON” 0 2 0 R/W 7
055 Conf A01 Configuration analog output 1; 0=rot.speed, 1=power, 2=Current 0 2 0 R/W 7
095 RstCstVals Zurücksetzen auf Werkseistellung (für Parameter 0.....99; 700....799)
4)
010 W0
Status requests (only readable)
# Display Name, Description min max fact. set. RS 485
1)
Data typ
2)
300* Unit remote controlled – R 0
301 Oil defic Oil deficiency turbopump – – – R 0
302* Rotation switch point attained – R 0
303 Error code Actual error code „no Err“, „Errxxx“ oder „Wrnxxx“ – R 4
304* Over temperature electronic drive unit – R 0
305* Over temperature turbopump – R 0
306* Set rotation speed attained – R 0
307* Turbopump accelerates – R 0
308 Set rotspd Set rotation speed TMP [Hz] 0 2000 – R 1
309 Act rotspd Actual rotation speed TMP [Hz] 0 2000 – R 1
310 TMP I-Mot Motor current TMP [A] 0.00 25.00 – R 2
311 TMP Op hrs Operating hours TMP [h] 0 65535 – R 1
312 PCS Softw Software version electronic drive unit 000000 999999 – R 1
313 TMP DClink Motor voltage TMP [V] 0 400 – R 1
314 Drv Op hrs Operating hours electronic drive unit 0 65535 – .R 1
315 TMP finspd Final rotation speed TMP [Hz] 0 2000 – R 1
316 TMP power Motor power TMP [W] 0 5000 – R 1
319 Cycl count Cycle counter 0 65535 – R 1
346 TMPmotTemp Motor temperature pump 0 400 – R 7
349 Drv Name Unit type Electronic Drive Unit 6
.
ASCII 32d 6
.
ASCII 127d TCP3k R 4
352 Drv Softw. Software motor control 6
.
ASCII 32d 6
.
ASCII 127d –R4
354 HW-version Hardware version 6
.
ASCII 32d 6
.
ASCII 127d –R4
360 Past Err1 Error storage, Position 1 (last error occuring) – R 4
361 Past Err2 Error storage, Position 2 – R 4
362 Past Err3 Error storage, Position 3 – R 4
363 Past Err4 Error storage, Position 4 – R 4
364 Past Err5 Error storage, Position 5 – R 4
365 Past Err6 Error storage, Position 6 – R 4
366 Past Err7 Error storage, Position 7 – R 4
367 Past Err8 Error storage, Position 8 – R 4
368 Past Err9 Error storage, Position 9 – R 4
369 Past Err10 Error storage, Position 10 – R 4
Set values (readable and writable)
# Display Name, description min max fact. set. RS 485 Data typ
2)
700 TMP RUTime maximum run-up time in mins 1 120 8 R/W 1
701 Switch pnt Rotation speed switchpoint [%] 50 97 80 R/W 1
707 TMProt set Rotation speed set value in rotation speed setting operations [%] 20.0 100.0 50.0
3)
R/W 2
710 BkP Poff P
min
for interval operations backing pump [W] 0 1000 0 R/W 1
711 BkP Pon P
max
for interval operations backing pump [W] 0 1000 0 R/W 1
717 Stbyrotset Drehzahlvorgabe im Standbybetrieb in % 20 100 66.7 R/W 2
720 Vent frequ Venting frequency as a % of the final rotation speed of the TMP 40 98 50 R/W 7
721 Vent time Venting time [s] 6 3600 3600 R/W 1
777
PumpRotMax
Max. rotation speed [Hz] 150 3000 777 R/W 1
794 Param. set Parameter set 0 = basic parameter set; 1 = extended parameter set 0 1 0 R/W 7
795 Servicelin Contains the service line 795=messages; ≠795 = # of the 2. param. set 309 R/W 7
797 Address Unit address 1 255 1 R/W 1
A number in bold type is a basic parameter set, e.g. “700 TMP RUTime”.
= Parameter setting is saved internal and preserves the value if mains is switched off.
1)
R = Parameter readable via interface /W = parameter writeable via interface.
2)
See Interface instruction ”Pfeiffer vacuum Protocol to RS-232 and -485” / PM 800 488 BN
3)
Function can only be affected via remote plug
4)
Effective only after mains ON/OFF
* Parameters are not shown in the LC display but displayed by symbols (line 4) or operable by the keys.
5.2. Parameter Overview TCP 3000, numerical
