Pfeiffer Vacuum TCP 3000 User Manual

4
2.1. For Your Assistance
Icons used
The following icons are used throughout all the figures of this
document:
Fore vakuumflange
Vent connection
Electrical connection
Item numbers
The item numbers are the same for all accessory items in all
figures.
Work instructions in the text
➡ Here you need to do something.
Abbreviations used
TMP Turbomolecular Pump
TPH Turbomolekular Pump for High Vacuum
TPU Turbomolekular Pump for Ultra High Vacuum
TCP Controller Turbomolecular Pump (Electronic Drive
Unit)
OTB OnTool Booster Pump
Text explanations (example)
[P:701] = selectable parameter number
«Param. Set» = Parameter designation
2.2. Product Description
The TCP 3000 electronic drive unit serves the purpose of
driving and monitoring PFEIFFER-VACUUM pumps, especially:
- Turbomolecular pump TPH 2303
- OnTool Booster 150
Scope of Delivery
The following items are delivered:
– TCP 3000
– Mating plug “Mains”
– Mating plug for the “Remote” socket
The TCP electronic drive unit is composed of the following
functional units:
– Electronic drive system monitoring and control
– Illuminated LC display providing information on the opera-
tional status of the turbomolecular pump
– Parameter selection and setup
– RS-232/-485 serial interface
– Remote control
Connection Options
The TCP 3000 electronic drive unit offers the following
connection options:
– Remote control (“Remote”)
– Master computer via RS-485/RS-232 serial interface
– Turbomolecular pump (“Pump”)
Proper Use
– The TCP 3000 electronic drive unit must be used only in
connection with special pumps from PFEIFFER-VACUUM
(see section 10 “Technical Data”).
– Compliance with installation, commissioning, operating
and maintenance instructions must be ensured.
Improper Use
Any of the following is considered as improper usage:
– The use for purposes, other than those detailed above, in
particular:
– connection of the drive unit to pumps and instrumentati-
on not specified for being operated by the drive unit;
– connection to instrumentation with components
carrying voltages which are not touch protected.
Any improper usage will void your liability and warranty
rights.
2. Getting to Know Your TCP 3000
