Pfeiffer Vacuum TCP 3000 User Manual

21
6.15. Switching Outputs
The following functions are assigned to the switching
outputs:
Switching output 1: (Remote: Pin 8 and
rreellaayy ccoonnttaacctt sswwiittcchh ppooiinntt
)
Active high after rotation speed switch point is reached.
The turbopump switch point is factory set to 80 % of the set
rotation speed
[[PP::330088]]
. For example, it can be used for a
“Pump ready” message.
Scwitching output 2: (Remote: Pin 9 and
rreellaayy ccoonnttaacctt eerrrroorr
)
The output function can be configured using the Parameter
«
001199 ::CCoonnff.. OOUUTT22
»
[[PP::001199]] RReemmoottee PPiinn 99
0
(factory
set) low: in case of error; power off
high: unit ready for peration
1 low: in case of error; warning or power off
high: unit ready for operation
2 low: in case of error; power or drive off
[[PP::002233]]
high: Pump in operation
