These Operating Instructions describe the operation of
PFEIFFER-VACUUM pumps. This manual forms part of the
complete operating instructions for your modular turbo pump
system. You will find further instruction manuals in the scope
of delivery (see table), to suit your particular combination of
components.
If, despite meticulous checks by ourselves, you should be
lacking information about our products, please contact your
PFEIFFER dealer, or phone the hotline on the back of this
manual.
All documentation is also available in PDF format.
The following operating instructions are available for our
pump range:
12.Accessories
13.Additional Information
PPrroodduukktt DDeeffiinniittiioonn MMaannuuaall NNoo
Turbomolecular pump Description of turbomolecular pump depends on pump type*
Turbo pump water cooling Description of water cooling PM 800 546 BE
Pfeiffer Vacuum Protocol RS-232/RS-485 Description of interface protocol PM 800 488 BE
Venting valve TVF 005 Description of venting valve PM 800 507 BE
Level Converter TIC 002 Description of pumping control via RS-232/RS-485 PM 800 549 BE
OnTool Booster Description of OnTool Booster PU 0021 BE
*Numbers and instructions can also be obtained from PFEIFFER-VACUUM Service or via our Homepage at www.pfeiffer-vacuum.de.
DDeessiiggnnaattiioonn QQuuaannttiittyy NNuummbbeerr-- RReemmaarrkkss
Pump cable (TPH 2303) 3m PM 051 863 -T Other lengths available
Pump cable (OTB 150) 3m PR 003 473 -T on request
Mains cable, Schuko, single-phase P 4564 309 HA
Level converter RS-485/RS-232 PM 051 054 -X
