BG 5195 BEN / A (2011-05) TPG261.oi 19
Select a location where the admissible maxi-
mum ambient temperature (→ 9) is not ex-
ceeded (e.g. due to sun irradiation).
DANGER
DANGER: line voltage
Products that are not professionally
connected to ground can be extremely
hazardous in the event of a fault.
Connect the product according to the local
regulations and ground it correctly.
The unit is supplied with a power cord. If the mains con-
nector is not compatible with your system, use your own,
suitable cable with protective ground (3
×1.5 mm
3
).
The socket must be
fuse - protected with
10 A
max
If the unit is installed in a switching cabinet, the mains
voltage should be supplied and turned on via a central
distributor.
3.3 Mains Power
Connector
