Pfeiffer TPG 261 - 5.2.2.2 Gauge Parameters

BG 5195 BEN / A (2011-05) TPG261.oi 77
Transmit: SPS <CR>[<LF>]
Receive: <ACK><CR><LF>
Transmit: <ENQ>
Receive: x,x,x,x <CR><LF>
│ │ │ │
│ │ │ └─ Status switching function 4
1)
│ │ │
│ │ └─ Status switching function 3
1)
│ │
│ └─ Status switching function 2
1)
│
└─ Status switching function 1
1)
1)
x = 0 –> off
1 –> on
Transmit: FIL [,x,x] <CR>[<LF>]
│ │
│ └─ Gauge 2 x = 0 –> fast
│ 1 –> medium
│ (default)
│ 2 –> slow
│
└─ Gauge 1
Receive: <ACK><CR><LF>
Transmit: <ENQ>
Receive: x,x <CR><LF>
│ │
│ └─ Filter time constant gauge 2
│
└─ Filter time constant gauge 1
Switching function
status
5.2.2.2 Gauge Parameters
Measurement value
filter
