Pfeiffer TPG 261 - Calibration factor

78
BG 5195 BEN / A (2011-05) TPG261.oi
Transmit: CAL [,x.xxx,x.xxx] <CR>[<LF>] (
)
│ │
│ └─ Gauge 2
│ log. 0.100 ... 9.990
│ (default = 1.000)
│ lin. 0.500 ... 2.000
│ (default = 1.000)
│
└─ Gauge 1
Receive: <ACK><CR><LF>
Transmit: <ENQ>
Receive: x.xxx,x.xxx <CR><LF>
│ │
│ └─ Calibration factor gauge 2
│
└─ Calibration factor gauge 1
The full scale value of the measurement range
(Full Scale) of linear gauges has to be defined
by the user; the full scale value of logarithmic
gauges is automatically recognized.
Transmit: FSR [,x,x] <CR>[<LF>]
│ │
│ └─ Gauge 2, x =
│ 0 –> 0.01 mbar
│ 1 –> 0.1 mbar
│ 2 –> 1 mbar
│ 3 –> 10 mbar
│ 4 –> 100 mbar
│ 5 –> 1000 mbar (default)
│ 6 –> 2 bar
│ 7 –> 5 bar
│ 8 –> 10 bar
│ 9 –> 50 bar
│
└─ Gauge 1
Receive: <ACK><CR><LF>
Transmit: <ENQ>
Receive: x,x <CR><LF>
│ │
│ └─ Measurement range gauge 2
│
└─ Measurement range gauge 1
Calibration factor
Measurement range
(F.S.) of
linear gauges
