Pfeiffer TPG 261 - 5.2.2.3 Gauge Control

82
BG 5195 BEN / A (2011-05) TPG261.oi
Transmit: SCx [,x,y,x.xxEsxx,y.yyEsyy] <CR>[<LF>]
│ │ │ │ │
│ │ │ │ └─ OFF threshold
│ │ │ │
│ │ │ └─ ON threshold
│ │ │
│ │ └─ Controlling source for gauge
│ │ deactivation, x =
│ │ 0 –> no control
│ │ 1 –> automatic deactivation
│ │ 2 –> manual deactivation
│ │ (default)
│ │ 3 –> external deactivation
│ │ 4 –> self control
│ │
│ └── Controlling source for gauge
│ activation, x =
│ 0 –> no control
│ 1 –> automatic activation
│ 2 –> manual activation (default)
│ 3 –> external activation
│ 4 –> hot start
│
└──── Controlled gauge, x =
1 –> Gauge 1
2 –> Gauge 2
Receive: <ACK><CR><LF>
Transmit: <ENQ>
Receive: x,y,x.xxEsxx,y.yyEsyy <CR><LF>
│ │ │ │
│ │ │ └─ OFF threshold
│ │ │
│ │ └─ ON threshold
│ │
│ └─ Controlling source for
│ deactivating the gauge
│
└── Controlling source for activating the
gauge
5.2.2.3 Gauge Control
Gauge control
