Pfeiffer TPG 261 - 5.2.2 Parameter Mode; 5.2.2.1 Switching Function Parameters

76
BG 5195 BEN / A (2011-05) TPG261.oi
Transmit: SPx [,y,x.xxxxEsxx,x.xxxxEsxx] <CR>[<LF>]
│ │ │ │
│ │ │ └ Upper threshold
1)
│ │ │ [in current
│ │ │ pressure unit]
│ │ │ (default =
│ │ │ depending on
│ │ │ gauge)
│ │ │
│ │ └─ Lower threshold
1)
│ │ [in current pressure unit]
│ │ (default = depending on
│ │ gauge)
│ │
│ └ Switching function assignment, y =
│ 0 –> Meas. channel 1
│ 1 –> Meas. channel 2
│
└─ 1 –> Switching function 1
2 –> Switching function 2
3 –> Switching function 3
4 –> Switching function 4
1)
Values can be entered in any format. They
are internally converted into the floating point
format.
Receive: <ACK><CR><LF>
Transmit: <ENQ>
Receive: y,x.xxxxEsxx,x.xxxxEsxx <CR><LF>
│ │ │
│ │ └─ Upper threshold
│ │ [in current
│ │ pressure unit]
│ │
│ └─ Lower threshold
│ [in current pressure unit]
│
└─ Switching function assignment
5.2.2 Parameter Mode
5.2.2.1 Switching
Function
Parameters
Threshold value
setting, allocation
