Pfeiffer TPG 261 - Example

90
BG 5195 BEN / A (2011-05) TPG261.oi
"Transmit (T)" and "Receive (R)" are related to Host.
S: TID <CR> [<LF>]
E: <ACK> <CR> <LF>
S: <ENQ>
E: TPR,CMR <CR> <LF>
Request for gauge identification
Positive acknowledgement
Request for data transmission
Gauge identifications
S: SEN <CR> [<LF>]
E: <ACK> <CR> <LF>
S: <ENQ>
E: 0,0 <CR> <LF>
Request for gauge statuses
Positive acknowledgement
Request for data transmission
Gauge statuses
S: SP1 <CR> [<LF>]
E: <ACK> <CR> <LF>
S: <ENQ>
E: 0,1.0000E-09,9.0000E-07 <CR> <LF>
Request for parameters of
switching function 1 (setpoint 1)
Positive acknowledgement
Request for data transmission
Thresholds
S: SP1,1,6.80E-3,9.80E-3 <CR> [<LF>]
E: <ACK> <CR> <LF>
Modification of parameters of
switching function 1 (setpoint 1)
Positive acknowledgement
S: FOL,1,2 <CR> [<LF>]
E: <NAK> <CR> <LF>
S: <ENQ>
E: 0001 <CR> <LF>
S: FIL,1,2 <CR> [<LF>]
E: <ACK> <CR> <LF>
S: <ENQ>
E: 1,2 <CR> <LF>
Modification of filter time constant
(syntax error)
Negative acknowledgement
Request for data transmission
ERROR word
Modification of filter time constant
Positive acknowledgement
Request for data transmission
Filter time constants
5.2.3 Example
