Pfeiffer TPG 261 - Operator key test

BG 5195 BEN / A (2011-05) TPG261.oi 89
Transmit: TKB <CR>[<LF>]
Receive: <ACK><CR><LF>
Transmit: <ENQ>
Receive: xxxx <CR><LF>
││││
│││└─ Key 4
x = 0 –> Not pushed
│││ 1 –> Pushed
│││
││└── Key 3
││
│└─── Key 2
│
└──── Key 1
Transmit: RST <CR>[<LF>]
Receive: <ACK><CR><LF>
Transmit: <ENQ>
Starts the test (repeats each
character, test is interrupted
with <CTRL> C)
Operator key test
RS232 test
