NEWVSI TECHNICAL MANUAL – PROGRAMMING PG DRIVES TECHNOLOGY
42 SK80151-1
5.2 Calibration Factor
This allows further fine calibration of the TruCharge battery gauge.
This is normally set at the factory and should not need further adjustment.
5.3 Low Battery Alarm
This parameter sets whether the level newVSI will signal a low battery condition.
O = Off,
1= Red LED flashing,
2= Red LED steady.
3= 1 Red and 1 Yellow LED
4= 1 Red and 2 Yellow LED
5=1 Red, 2 Yellow and 1 Green LED
The audible alarm will sound if the newVSI is programmed between 1-5.
5.4 Low Battery LED
This parameter allows users to change the color of the first LED in the TruCharge display.
The programmable options are Red or Yellow.
This programmable option enables the controller to comply with GB9706.01 1995 section 6.7. Compliance with this standard is
required in some instances to sell product into China.
5.5 Low Voltage Cut Out
This parameters sets the battery voltage threshold that must be read for the period set by Low Voltage Time before the controller
ceases to operate.
This parameter is programmable between 16V and 22V in steps of 0.5V.
5.6 Low Voltage Time
This parameters sets the time the controller must read the low voltage cut before the controller ceases to operate.
This parameter is programmable between 1 and 255 seconds
5.7 Output Voltage
This sets the value of voltage applied to the motors when the joystick is fully deflected and the relevant speed, forward or reverse,
is set to 100%. This feature allows you to choose a motor voltage value such that the wheelchair's top speed will remain constant
all the time the battery voltage is above that value.
This value can be set between 20 and 25V in steps of 0.5V.
6 General Parameters
6.1 Fast Brake Rate
Adjusts the deceleration rate used while fast braking. Fast braking is when the joystick is pulled to the reverse position to make a
faster stop.
