PG DRIVES TECHNOLOGY NEWVSI TECHNICAL MANUAL – SPECIFICATIONS
SK80151-1 67
1 Electrical Specifications
Supply Voltage: 24Vdc
Operating Voltage: 16Vdc to 35Vdc
Reverse Battery Protection: -40Vdc
PWM Frequency: 19.5kHz ± 1%
Brake Voltage: 24Vdc
Brake Current: 1.25A max.
Battery Charging Current: 12Arms max.
Charger Connector: Use only Neutrik NC3MX
Maximum Drive Current: 50A
Moisture Resistance: IPx4
Operating Temperature: -25°C to +50°C
Storage Temperature: -40°C to +65°C
EMC tested on sample wheelchair:
Susceptibility: Tested at 30V/m to EN12184 and ANSI/ RESNA requirements
Emissions: To EN55022 Class B
ESD: IEC801 part 2
