REMOTE ALARM TERMINAL
The alarm is relayed to a remote location when a remote alarm device (commercially available) is
connected to the remote alarm terminal. Installation of a remote alarm device is recommended when the
unit is installed in an unattended location so that the operator of the unit is notified of the alarm.
Contact our representative or agent to arrange the installation of a remote alarm device.
Location of remote alarm terminal: upper back side
Allowable contact capacity: DC 30 V, 2 A
Contact output:
Connection Normal status Abnormal status
Between COM. and N.O. open closed
Between COM. and N.C. closed open
The remote alarm terminal will be in alarm mode when the power supply cord is unplugged or the power
switch is turned off because this will be interpreted as a power failure.
The operation of the remote alarm terminal is conjunction with the alarm buzzer. Therefore, the
operation of the remote alarm terminal can be canceled by pressing the buzzer stop key (BUZZER), but
the operation for the power-failure alarm cannot be canceled.
Use a twisted shielded wire for the connection.
Type: UL 2343, UL 2448, UL 2464, UL 2552, UL 2623
Length: 30 m max.
