SPECIFICATIONS
Product name Biomedical freezer
MDF-U5412
Medical purpose Storage of DNA, plasma
External dimensions W804 mm x D772 mm x H1802 mm
Internal dimensions W658 mm x D607 mm x H1272 mm
Effective capacity 482 L
Exterior Painted steel
Interior Styrol resin
Door Painted steel x 2
Storage container Small storage container; W290 mm x D536 mm x H136 mm
Large storage container;
W290 mm x D536 mm x H238 mm
Insulation Rigid polyurethane foamed-in place
Access port Inner diameter; 30 mm, Back side
Compressor Hermetic type, Output; 450 W
Condenser Wire and tube type
Evaporator Tube on sheet
Refrigerant R-404A
Temperature controller Electronic control system
Temperature display Digital display
Thermal sensor Thermistor sensor
Alarm High-temperature alarm, Low-temperature alarm, Power-failure alarm
Remote alarm contact Allowable contact capacity: DC 30 V, 2 A
Battery For power failure alarm, Nickel-metal-hydride battery
DC 6 V, 1100 mAh, Automatic charge
Weight 132 kg
Accessories 2 keys, 1 scraper, 6 small storage containers, 4 large storage containers
Optional components Temperature recorder (MTR-G85C, MTR-4015LH)
Interface board (MTR-480, MTR-L03)*
Design or specifications are subject to change without notice.
Refer to the updated catalogue when ordering an optional component.
*: For the data acquisition system MTR-5000 user only. Contact our sales representative or
agent for purchase.
