37
TEMPERATURE RECORDER (OPTIONAL)
The chamber temperature can be recorded and checked by installing an optional temperature recorder
(MTR-G85C or MTR-4015LH).
Contact our sales representative or agent to arrange purchase of the temperature recorder.
Main specifications of temperature recorder
MTR-G85C MTR-4015LH
Recording range Between -100
o
C and +40
o
C Between -40
o
C and +14
o
C
Feed speed of
recording paper
1-day/turn, 7-day/turn,
32-day/turn
31-day/batch
Recording paper Circular type Strip type
Power source Supplied from the freezer Dry cell
For the installation of temperature recorder MTR-G85C, the recorder mounting bracket MPR-S7 is
necessary.
For the installation of temperature recorder MTR-4015H, the recorder mounting bracket MPR-S30 is
necessary.
MTR-4015LH
MTR-G85C
