170B6 LCD
Electrical Instructions
# Resolution H-Frequency Pixel rate V-Frequency Comment
1 640X350 31.5KHz 25.175 70Hz IBM VGA 10h
2 720X400 31.5KHz 28.322 70Hz IBM VGA 3h
3 640X480 37.5KHz 31.501 75Hz
4 640X480 35.0KHz 30.24 67Hz
5 640X480 31.5KHz 25.175 60Hz
6 800X600 35.2KHz 36 56Hz
7 800X600 46.9KHz 49.498 75Hz
8 800X600 37.9KHz 40 60Hz
9 832X624 49.7KHz 57.28 75Hz MAC
10 1024X768 60.0KHz 78.75 75Hz
11 1024X768 48.4KHz 65 60Hz
12 1152X870 68.7KHz 100 75Hz MAC
13 1152X900 71.8KHz 108 76Hz SUN Mode II
14 1280X1024 64.0KHz 108 60Hz
15 1280X1024 80.0KHz 135 75Hz
2.3 Allowed85Hzoverscansignalmodespecified
Once the signal input of PC is 85Hz, this monitor is able to display
at least for 10 minutes. An attention signal appears and shows "This
is 85Hz overscan, change computer display input to 1280X1024@
60 Hz "
Dot rate (MHz) H. Freq (KHz) Mode Resolution V. Freq (Hz)
36.000 43.269 VESA 640 * 480 85.008
5 56.250 53.674 VESA 800 * 600 85.061
94.500 68.677 VESA 1024 * 768 84.997
Allowed TV PAL signal mode specified TV PAL Mode, this mode can be
adjusted and saved.
Dot rate (MHz) H freq (KHz) Mode Resolution V freq (Hz)
27.000 31.25 TV PAL 688*556 50
3. Power Supply
3.1 Set up the AC I/P at 90VAC, add (B)
2.7A loading to +12V O/P and DC O/P voltage is 12V +/- 1.2V,
2.1A loading to 5V O/P and DC O/P voltage is 5V +/- 0.25V
3.2 Check voltage at (B)
5V O/P should be within the range 5V +/- 0.25V
12V O/P should be within the range 12V +/- 1.2V
4. Display Adjustment
4.1 Access to factory mode (RS232) in auto-alignment system
The communication protocol switches to RS232.
4.2 Auto color adjustment (B)
Apply a 640*480/60Hz signal with 16 level grey test pattern, set
brightness control at 100%, and contrast control at 50%. Adjust
the R.G. B. offset, and gain to calibrate the color smoothly and
64-grey level distinguishable.
4.3 Adjustment of WHITE-D (B)
Apply a 1280*1024 / 60Hz signal with white pattern, set
brightness control at 100%, and contrast control at 50%. Adjust
the R, G, B Sub-Gain, for the screen center, the 1931 CIE
chromaticity (X, Y) co-ordinates shall be
9300°K 6500°K
x (center) 0.283 ± 0.020 0.313 ± 0.020
y (center) 0.297 ± 0.020 0.329 ± 0.020
Use Minolta CA-210 for color coordinates and luminance check.
Luminance is > 200 Nits in the center of the screen when brightness at
100% and contrast set to 100%.
4.4 Adjustment of sRGB (B)
Apply a 1280*1024/ 60Hz signal with white pattern, set brightness
control at 100%, and contrast control at 50%. Adjust the R, G, B
Sub-Gain, for the screen center, the 1931 CIE chromaticity (X, Y)
co-ordinates shall be;
sRGB
x(center) 0.313 ± 0.008
y(center) 0.329 ± 0.008
Ynits 180 ± 10
4.5 EEPROM presetting (B)
After finishing all the adjustment, set:
Brightness control to 100%
Contrast control to 50%
OSD position at middle of screen
COLOR adjusts to 6500K color.
VOLUME control to 60%
