GENERAL PRODUCT SPECIFICATION(Continued)
2.2 Scanning frequencies
H-Frequency. : 30K
83 KHz
V-Frequency. : 56 - 76 Hz
2.3 Video dot rate. : < 140 MHz
2.4 Power input. : 90-264 V AC, 50/60 ± 2Hz
2.5 Power consumption. : < 35 W maximum (without audio)
: < 45 W maximum (with audio)
2.6 Dimensions. : 375(W) * 431(H) * 210(D) mm
2.7 Weight. : 5.62 kg
2.8 Functions:
(1) D-Sub analog R/G/B separate inputs, H/V sync separated, Composite (H+V) TTL level, SOG
sync.
(2) DVI-D digital Panel Link TMDS input
2.9 Ambient temperature: 5 °C-40°C
2.10 Regulatory compliance:
Safety
B, CCIB / CCEE(China), CE(Europe), CSA(Canada), DEMKO(Nordic),
EZU(Czech), FIMKO(Nordic), Gost(Russia), IEC 950 CB Report, NOM
NYCE(Mexico), PSB(Singapore), SEMKO(Nordic),SISIR CPA(Singapore),
TUV(Germany), UL(USA),
* UL2601-1(NAFTA), EN60601(EU) and IEC60601-1(WW)
EMI
C-tick, CE(Europe), FCC(USA), IC(Canada), VCCI(Japan),BSMI,
*IEC60601-1-2 (EU)
Ergonomics
E2000, MPRII(Sweden), Nutek(Sweden), TCO99, TCO03, TUV/GS,
TUV/ERG, EPA, ISO13406-2
Compatibility PC2001, Windows 2000, Windows 98/Me, Windows XP, NSTL
* Medical compliance only applies for dedicated models.
3.0 Electrical characteristics
3.1 Interface signals
There are two main display interface input signals (D-sub and DVI-D) including the additional peripheral
interface
inputs (Audio & USB):
1). D-shell Analog
Input signal: Video, H-sync, V-sync,
Video: 0.7 V p-p, input impedance, 75 ohm
Sync. : Separate sync TTL level, input impedance 2k2 ohm terminate
H-sync Positive/Negative
V-sync Positive/Negative
Composite sync TTL level, input impedance 2k2 ohm terminate (Positive/Negative)
Sync on green video 0.3V p-p Negative. (Video 0.7 V p-p Positive)
2). DVI-D Digital
Input signal: Single TMDS link (Three channels: RX0-/+, RX1-/+, RX2-/+)
