GENERAL PRODUCT SPECIFICATION(Continued)
11 1024X768 48.4KHz 65 60Hz
12 1152X870 68.7KHz 100 75Hz MAC
13 1152X900 71.8KHz 108 76Hz SUN Mode II
14 1280X1024 64.0KHz 108 60Hz
15 1280X1024 80.0KHz 135 75Hz
Note: 1. Screendisplays perfect picture at 15 factory-preset modes.
2. Screendisplays visible picture with OSDwarningwheninputmodes are other then 34 preset modes
4.3 Brightness: 200 nits (at panel color temperature, Screen center point, Fig. 1)
4.4 Image size
4.4.1 Actual display size
338x270mm
4.5 Brightness uniformity
Set contrast at 50% and turn the bright
ness to get average above 200 nits at center of the screen.
Apply the Fig1.Itshould comply with the followingformula:
Minimumluminance of ninepoints (brightness)
>= 0.75 (Min)
Maximumluminance of ninepoints (brightness)
4.6 Check Cross talk (S)
Apply Pattern 2. Set contrastat50%and brightness at 100 %. Measure A. Then
outpu
t Pattern 3and measure A . The cross talk value:
ABS(A- A
)
¾¾¾¾¾¾¾¾¾ X 100 % < 1.5 % (Max)
A
4.7 White color adjustment
There are three factory preset white color 9300K, 6500K, sRGB.
Apply full white pattern,with brightness in 100 % position and the contrast control at 50 % position. The 1931 CIE
Chromaticity (color triangle)diagram (x,y) coordinate for the screen center should be:
9300K CIE coordinates X = 0.283 ± 0.020
Y = 0.297 ± 0.020
6500K CIE coordinates X = 0.313
± 0.020
Y = 0.329 ± 0.020
sRGB CIE coordinates X = 0.313 ± 0.008
Y = 0.329 ± 0.008
5.0 Mechanical characteristics
5.1 Controls
Front. :
DC power switch
OSDfunction key
BRAND:PHILIPS
17 inch LCD Monitor
TYPE :170B6CG/00
8639 000 16159
2004-12-24
2004-12-24
590
Peter V.
