GENERAL PRODUCT SPECIFICATION(Continued)
Pin No. Description
1 T.M.D.S. data2-
2 T.M.D.S. data2+
3 T.M.D.S. data2 shield
4 No Connect
5 No Connect
6 DDC clock
7 DDC data
8 No Connect
9 T.M.D.S. data1-
10 T.M.D.S. data1+
11 T.M.D.S. data1 shield
12 No Connect
13 No Connect
14 +5V Power
15 Ground (for +5V) - Cable detect
16 Hot plug detect
17 T.M.D.S. data0-
18 T.M.D.S. data0+
19 T.M.D.S. data0 shield
20 No Connect
21 No Connect
22 T.M.D.S clock shield
23 T.M.D.S. clock+
24 T.M.D.S. clock-
3.2.3 Audio Cable
Length. : 1.8 M +/- 50 mm
Connector type. : 3.5-mini jack with lime color on the both end.
3.2.4 USB Cable (High Full Speed)
Length. : 1.8 M +/- 50 mm (Max.)
Connector type. : USB- B Plug (Input)
USB- A Plug (Output)
Pin Assignment:
Pin No. Description
1 VBUS
2 Data+
3 Data-
4GND
3.2.5 Software control functions via OSD/control
OSD (On Screen Display) function
(1) Analog interface OSD:
Adjustable functions:
