GENERAL PRODUCT SPECIFICATION(Continued)
Remark: Audio Selection - Stand-alone - On: Isolate video and audio control input
Stand-alone - Off: Integrate video and audio control input
Mute - On: Turn off Audio input
Mute - Off: Turn on Audio input
Reset - No: Exit
Yes: Auto adjustment for displaying timing mode and recall
factory preset
3.3 Timing requirement
3.3.1 Mode storing capacity
(1) Factory preset modes. : 15
(2) Preset modes. : 34
3.3.2 Factory/ Preset timings
The factory settings of size and centering are according to the reference timing charts
(See as below)
MODE NO. 1 2 3 4
RESOLUTION 640 x 350 720 x 400 640 x 480 640 x 480
Dot clock(MHz) 25.175 28.321 25.175 30.24
f h 31.469kHz 31.468kHz 31.5kHz 35 kHz
A ( us ) 31.778(800 dots) 31.78(900dots) 31.778(800 dots) 28.571 (864 dots)
B ( us ) 3.813(96 dots) 3.813(108dots) 3.813( 96 dots) 2.116 ( 64 dots)
C ( us ) 1.907(48 dots) 1.907(54dots) 1.907( 48 dots) 3.175( 96 dots)
D ( us ) 25.422(640 dots) 25.42(720dots) 25.422( 640 dots) 21.164( 640 dots)
E ( us ) 0.636(16 dots) 0.636(18dots) 0.636( 16 dots) 2.116( 64 dots)
f v 70Hz(70.09) 70Hz(70.085) 60Hz 67Hz
O (ms ) 14.27(449 lines) 14.27(449 lines) 16.683 (525 lines) 15 (525 lines)
P ( ms ) 0.064(2 lines) 0.064(2 lines) 0.064 ( 2 lines) 0.086( 3 lines)
Q (ms ) 1.907(60 lines) 1.112(34 lines) 1.049 ( 33 lines) 1.114( 39 lines)
R ( ms ) 11.12(350 lines) 12.71(400 lines) 15.253 (480 lines) 13.714(480 lines)
S ( ms ) 1.175(37 lines) 0.381(13 lines) 0.317 ( 10 line ) 0.086( 3 line )
SYNC. H/V +/- -/+ - / - - / -
POLARITY
SEP . SYNC Y Y Y Y
MODE NO. 5 6 7 8
RESOLUTION 640 x 480 640 x 480 640x480 800 x 600
Dot clock(MHz) 31.500 31.501 36 36
f h 37.861kHz 37.5kHz 36kHz 35.2kHz
A ( us ) 26.413(832 dots) 26.667 (840 dots) 23.111 (832 dots) 28.444(1024 dots)
B ( us ) 1.270(40 dots) 2.032 ( 54 dots) 1.556 (56 dots) 2.000 ( 72 dots)
C ( us ) 3.810(120 dots) 3.81 ( 120 dots) 2.222 ( 80 dots) 3.556 ( 128 dots)
D ( us ) 20.317(640 dots) 20.317 (640 dots) 17.778 (640 dots) 22.222( 800 dots)
E ( us ) 1.016(32 dots) 0.508 ( 26 dots) 1.555 (56 dots) 0.666 ( 24 dots)
f v 72.809Hz 75Hz 85Hz 56Hz
O (ms ) 13.735(520 lines) 13.333(500 lines ) 11.763 (509 lines ) 17.778 (625 lines)
P ( ms ) 0.079(3 lines) 0.08(3 lines ) 0.069 ( 3 lines ) 0.057 ( 2 lines)
Q (ms ) 0.528(20 lines) 0.427 ( 16 lines ) 0.578 ( 25 lines ) 0.626 ( 22 lines)
R ( ms ) 12.678(480 lines) 12.8 (480 lines ) 11.093 (480 lines ) 17.066 (600 lines)
S ( ms ) 0.45(17 lines) 0.026(1 lines) 0.023(1 lines) 0.029 ( 1 line )
SYNC. H/V -/- - / - -/- + / +
POLARITY
SEP . SYNC Y Y Y Y
